Specifications
Product Details
- SoCs: Silicon Labs MG24, ESP32-S3 (USB-serial bridge)
- Power/Data: USB-C, 5 V DC, 500mA
- Supported Protocols: Zigbee 3.0, Thread
Antenna Characteristics
Note: Different building materials and placement of the unit will affect the wireless connectivity range.
- Frequency range: 2400-2483.5 MHz
- Transmit power: 10 dBm (Europe) / 8 dBm (rest of world)
- Peak gain: 4.16 dBi
- Radiation pattern: Omnidirectional
- Dimensions: 24 mm diameter, 164 mm height
Environmental Conditions for Operation
- Environment: Indoor use only
- Temperature: 0°C to 65°C (32°F to 149°F) | Antenna: -40°C to +85°C
- Humidity: Non-condensing
- Care Instructions: Keep in a dry, non-dusty environment to prevent damage. Do not leave the unit in direct sunlight or near any heat source to avoid overheating.
In the Box
- Antenna + Base
- 1.5m USB-C cable (USB 2.0/3.0)
- Quickstart guide
- Warranty and Safety Information
